Features
Features
Flex bonded cords are strongly bonded to the body of the belt resulting in equal load distribution and the absorption of bending stress without cord deterioration
Gates® curves provide proper cord support and full contact with the sheave-groove for uniform loading, uniform wear, and increased belt life
The Flex-Weave® cover is constructed for longer cover life, providing extended protection to the core of the belt from oil, dirt, and heat
Static conductive (ISO 1813) and can as such be used in the conditions described in the directive 2014/34/EU- ATEX
Belt edge is machined for even sheave groove contact, resulting in smoother running, less slip and wear
Match system sizes meet gates uniset tolerances, they can be installed without matching
High quality rubber compound protects the belt against heat, ozone and sunlight
The belt will not catch fire from heat buildup, even with severe slippage
Long belt life reducing replacement and maintenance costs
Excellent performance/cost ratio
Reliability and efficiency
Specifications
Specifications
Package Quantity-1
Package Description-1/PK
UPC-072053201475
Package Height-2 in
Package Length-15 in
Package Volume-0
Package Width-6 in
Package Weight-0.24 lb
Manufacturer Name-Gates Corp
Manufacturer Part Number:A34
Brand Name-Gates®
Application
Application
For all industrial applications including v-flat drives
Standards
Standards
Standards/Approvals-ARPM/RMA IP-3-2/IP-3-3|REACH Compliant|RoHS 2 Compliant
Warranty-
