Features
Features
Nylon material with excellent resistance to impact fracture even at low temperatures below 32 deg F
Lighter weight design
More open design around the swivel and hose opening allows more space for removing and attaching hose to the reel
Steel guide arm and base are stamped with ribs and gussets to insure maximum strength and lightest possible weight
Full flow stress free swivel design - full flow swivel combines the highest grade seal design and materials with bearing areas to insure maximum service life
Hose is plumbed into the base to eliminate the risk of undue stress on the swivel
Declutching arbor eliminates reverse spring winding and torsions latch spring is virtually unbreakable
High quality spring steel is used and conditioned to insure there are no imperfections offering maximum service life
Individually powder coated components along with the composite spool offers the maximum protection from premature corrosion
1/2 in female NPTF inlet
1/4 in male NPTF outlet
150 deg F maximum temperature rating
Specifications
Specifications
Package Quantity-1
Package Description-1/PK
UPC-699567000051
Package Height-19 in
Package Length-17 in
Package Volume-2532 cu-in
Package Width-6.25 in
Package Weight-27 lb
Manufacturer Name-Reelcraft Industries
Manufacturer Part Number:A5850 OLP
Brand Name-Reelcraft®
Application
Application
Air and Water Applications
Standards
Standards
Standards/Approvals-PROP65: Cancer and Reproductive Harm www.P65Warnings.ca.gov
Warranty-
