Features
Features
Steel guide arm and dual pedestal base are stamped with ribs and gussets and robotically welded to insure maximum strength and lightest possible weight, the unitized cast fluid path and ratchet reduce wearable parts and ease of assembly
Full flow stress free swivel design - full flow swivel combines the highest grade seal design and materials with bearing areas to insure maximum service life
Unitized cast aluminum fluid path with built-in declutching arbor virtually eliminates possibility of leakage and spring damage due to reverse winding, only the highest quality spring steel is used and conditioned to insure there are no imperfections offering maximum service life
Individually powder coated components offer the maximum protection from premature corrosion
Hose anti latch-out feature ensures hose retracts every time
Containerized spring assembly provides safer and easier handling during maintenance
Two sealed ball bearings for smooth rotation of main shaft
1 in female NPTF inlet, 3/4 in male NPTF outlet
